SuperTechno 50

  • Max. Lens height: 50 ft
  • Max. Telescopic extent: 37 ft 6 in
  • Max. Telescopic speed: 6.5 ft/sec.
  • Door Clearance: 6 ft 11 in
  • Max camera weight: 80 lbs
  • Total weight: 5100 lbs
Detailed Specs

SuperTechno 30

  • Max. Lens height: 30 ft
  • Max. Telescopic extent: 22 ft
  • Max. Telescopic speed: 9.2 ft/sec.
  • Door Clearance: 6 ft 11 in
  • Max camera weight: 80 lbs
  • Total weight: 2640 lbs
Detailed Specs

SuperTechno 22

  • Max. Lens height: 22 ft
  • Max. Telescopic extent: 17 ft
  • Max. Telescopic speed: 6.2 ft/sec.
  • Door Clearance: 6 ft 11 in
  • Max camera weight: 80 lbs
  • Total weight: 1544 lbs
Detailed Specs

SuperTechno 15

  • Max. Lens height: 15 ft
  • Max. Telescopic extent: 10 ft
  • Max. Telescopic speed: 2.5 ft/sec.
  • Door Clearance: 5 ft 5 in
  • Max camera weight: 80 lbs
  • Total weight: 1153 lbs
Detailed Specs

Remote Heads

Active Head

  • Improved stabilization levels which allow for a balanced picture even under extremely rough operating conditions
  • High angular velocity on all axes
  • Compact size and light weight
  • Fast and effective re-balancing and calibration
  • 360 degree pan and roll function
  • Solid and reliable construction
  • Quick assembly
  • Remote controlled handling of lens parameters (Focus, Iris, Zoom)
Height: 895 mm max
Width: 745 mm
Depth: 630 mm
Power supply AC: 220V~ +/-15% ^5A max
Power supply DC 19-72 VDC@ 1kW peak
Pan angualr speed (max): 200 deg/sec
Tilt angular speed (max): 200 deg/sec
Roll angular speed (max): 200 deg/sec
Pan angular acceleration: 600 deg/sec²
Tilt angular acceleration (max): 800 deg/sec²
Roll angular speed (max): 1000 deg/sec²
Weight: 27 kg / 59.5 lbs


TaloN Head

Designed and built by Academy Award winning motion picture engineers, the Cinema Pro has been chosen by DPs and producers around the world for its smoothness, stability, and versatile feature set. In production for many years now, the Cinema Pro is extremely reliable, easy to set up and operate, and capable of imperceptibly slow or lightning fast moves with no sacrifice in stability. Carrying an impressive set of standard features and a proud pedigree, the Cinema Pro outperforms the competition at a fraction of the price and works with a huge range of film and video cameras.

The hand wheels offer fully independent, scalable control of pan and tilt, mimicking the classic gear head from the world of feature filmmaking. The hand wheels are slaved to the advanced console, which features a superb 3-axis joystick with customizable response for pan/tilt/zoom, oversize control knobs for focus and menu adjust, backlit keypad, and a whole host of parametric menu settings and interface options. The system is compatible with virtual set software, motion data import/export, and is capable of controlling servo lenses directly or can be integrated seamlessly with our TOC external lens drive motor system.


Joystick control for Pan/Tilt/Zoom, separate Knob for Focus
Record and move to up to 2000 marked positions
Record and playback 1 hour and up to 2000 takes
Share recorded data w/ laptop: upload/download
Programmable max. speeds for individual motors
Programmable smoothing controls for each motor
Precise homing control via pushbutton commands
2500′ max std extension, longer w/ fiber optic option
Wireless Option available
Programmable motion limits for both pan & tilt
Servo tuning available at Full Function Remote
Fuji/Canon/Preston serial & analog lens control
Zoom Compensation for smooth moves at telephoto
Camera sync. feature for frame-accurate shots
Advanced Intervalometer provides 3 modes for stretching moves in time
Extremely rigid for smooth motion @ telephoto
Full slip rings for continuous 360 degree motion

500 hd Slider

500 HD

The 500 HD SLIDER is a professional light weight robotic camera head for TV & Film. It can carry Cameras of up to 30kg with a remarkable degree of precision and control. Specifically targeted at High Definition applications where high resolution of movement is critical.

The 500 HD is the high resolution successor to the standard 500 .

Having all of the successful features of the standard 500, this enhanced version boasts some formidable extras:

New servo drive with intelligent power management to further increase the already impressive torque output by 30%
Motor temperature monitoring that profiles current parameters
High resolution output gives about 4 million steps per revolution of gearbox.
Gearbox parameters & software can be changed via serial link
Even quieter than the standard 500
Next generation anti-backlash system

Weight Of Universal Gearbox (each) 4lbs (1.8 kg)
Speed Range 2 seconds to 24 hours
Maximum recommended Camera Payload 60 lbs (27kg)
Gearbox Water resistance IP 64
Power to Head 28 V DC (Average 1.2 amps)
Control Data to Head RS 232


Dynamic Remote Systems was founded by Craig Nix. After 15 years as a freelance

Technocrane and remote head technician he decided to start his own company.

Starting with just the one 30ft Technocrane in Atlanta we have expanded rapidly to having
15ft 22ft 30ftand 50ft Technocranes

We also have an electric tracking vehicle.

Focusing on the needs of our clients in an ever evolving industry Dynamic is driven to

give the best service possible.

We have a very knowledgeable and creative team of techs to help solve complex shots

Don’t hesitate to challenge us with your ideas as we believe anything can be done.

We also have access to a team of machinists to build any specialty mounts needed.

Veiw our credits on IMDB


Please contact us for rental information. We would love to here from you.


Phone:  602.405.6541


  Technocrane Atlanta
